一. Features

Fully automated process control via programmable logic controller (PLC).

Uses a Siemens PLC.

7-inch Siemens display screen (Chinese/English interface; memory for 3 filling programs).

Parameters can be adjusted without stopping the machine.

Automatic control of liquid inlet and CO2 counter-pressure in the filling machine's buffer tank.

Filling zone operation features both automatic and manual control modes.

Negligible product loss; consistent filling volume.

Customizable for specific container types provided by the customer (e.g., 330ml/500ml/1L cans).

Highest production capacity in its class.

Equipped with automatic lid placement and automatic capping mechanisms.

Automated filling process control.

Manual can loading; automatic filling, conveying, lid placement, and capping.

二. Technical Parameters

Dimensions: 4000mm x 900mm x 2100mm

Product Loss Rate: < 2‰

Net Weight: 510 kg

Applicable Containers: Fully customizable based on customer-provided container types

Production Capacity: 600–1000 cans/hour

Buffer Tank Volume: 70L

Power Supply: 3-phase 380V, 50Hz

Total Power: 1.5 kW
